Chrome/bright trim

Around Side WindowsYes

Tyres

Tyre Width205

Tyre Profile55

Tyre Speed RatingV

Tyre Load Index91

TypeConventional/summer

Official Brochure Tyre SizeYes

Diameter16

Paint

TypeGloss

Roof rails

ColourBlack

Door mirrors/cameras

TypeElectrically Adjustable

HeatedYes

ColourPainted

Indicator LightsYes

Rear windscreen

TypeFixed

WipersIntermittent

Windscreen wipers

Rain SensorYes

Wheels

Rim TypeAlloy

Rim Diameter (in)16

Rim Width (in)7.5

Rim Diameter (cm)40.6

Rim Width (cm)19

External dimensions

Overall Length (mm)4667

Overall Width (mm)1814

Overall Height (mm)1495

Ground Clearance Unladen (mm)140

Wheelbase (mm)2686

Front Track (mm)1549

Rear Track (mm)1540

Kerb To Kerb Turning Circle (mm)10400

Wall To Wall Turning Circle (mm)11050

Overall Length (in)183.7

Overall Width (in)71.4

Overall Height (in)58.9

Ground Clearance Unladen (lbs)5.5

Wheelbase (in)105.7

Front Track (in)61

Rear Track (in)60.6

Kerb To Kerb Turning Circle (ft)34.1

Wall To Wall Turning Circle (ft)36.3

Internal dimensions

Headroom Front (mm)983

Headroom Rear (mm)995

Hip Room Front (mm)1454

Hip Room Rear (mm)1449

Shoulder Room Front (mm)1398

Shoulder Room Rear (mm)1378

Headroom Front (in)38.7

Headroom Rear (in)39.2

Hip Room Front (in)57.2

Hip Room Rear (in)57

Shoulder Room Front (in)55

Shoulder Room Rear (in)54.3

Load compartment capacity

Rear Seat Up To Lower Window (l)610

Rear Seat Down To Roof (l)1740

Measurement StandardVDA

Rear Seat Up To Lower Window (cu Ft)21.5

Rear Seat Down To Roof (cu Ft)61.4

Fuel tanks

TypeMain

Capacity (l)50

Capacity (gal)13.2

Capacity (UK Gallons)11

Weights

Gross Vehicle Weight (kg)1927

Published Kerb Weight (kg)1295

Gross Trailer Weight Braked (kg)1800

Gross Trailer Weight Unbraked (kg)632

Measurement StandardEU

Gross Vehicle Weight (lbs)4248

Published Kerb Weight (lbs)2855

Gross Trailer Weight Braked (lbs)3968

Gross Trailer Weight Unbraked (lbs)1393

Disc brakes

Number Of4

Number Of Ventilated Discs2

Parking distance sensors

TypeSensor

Parking distance system

TypeSensor

Headlights

Lens TypeComplex Surface

Bulb Type (low Beam)Halogen

Bulb Type (high Beam)Halogen

Headlight control

Dusk SensorYes

Height AdjustmentManual

Front airbag

Occupant Switch OffYes

Head restraints

Height AdjustableYes

Number3

Front seat belts

Seat PositionPassenger

Pre-tensionersYes

Height AdjustableYes

Rear seat belts

Seat PositionCentre

Type3-point

Anti collision system

Activates Brake LightsYes

Driver MonitorYes

Automatic BrakingYes

Automatic Emergency BrakingYes

Brakes At Low SpeedFront

Pedestrian & Cyclist Avoidance SystemYes

Visual/acoustic WarningYes

Anti-theft protection

Interior MonitoringYes

Cruise control

Adaptive Cruise ControlYes

Limited slip differential

TypeElectronic

Engine

Cc1598

Litres1.6

Bore79.5

Stroke80.5

Compression Ratio16

Number Of Cylinders4

ConfigurationIn-line

Number Of Valves Per Cylinder4

Engine CodeDDYA

Compression Ratio (high)16

Compressor

CompressorTurbo

Number Of1

Emission control level

Standard MetEU6.2 (C And D-Temp)

CO2 Level - G/km Combined103

NOx Level (g/km)0.035

Fuel system

Injection/carburationDiesel Common Rail

Fuel

Fuel TypeDiesel

Generic Primary Fuel TypeDiesel

Performance

Maximum Speed (km/h)198

Acceleration 0-62mph (s)10.4

Maximum Speed (mph)123

Power

Measurement StandardISO

Maximum Power KW85

Maximum Power Hp/PS115

Rpm For Maximum Power (low)3250

Maximum Torque Nm250

Rpm For Maximum Torque (low)1750

Primary Or Secondary Fuel Power FigurePrimary

Power steering

Vehicle Speed ProportionalYes

TypeElectric

Suspension

TypeTorsion Beam

Anti-roll BarYes

Wheel DependenceSemi-independent

Spring TypeCoil

Main service

Distance (km)32187

Period (mths)24

Variable Distance/periodYes

Distance (miles)20000

Fuel consumption

StandardWLTP ICE

Urban (l/100km)4.6

Country/highway (l/100km)3.5

Combined (l/100km)5

Urban (km/l)21.7

Country/highway (km/l)28.6

Combined (km/l)20

Combined Vehicle Range (km)1000

Calculated Vehicle Range (km)1000

Combined Vehicle Range (miles)621

Calculated Vehicle Range (miles)621

SourceEU6d-Temp

Combined L/100km Low Vehicle5.2

Combined L/100km High Vehicle5.7

Combined Km/l Low Vehicle19.2

Low Phase L/100km Low Vehicle5.9

Low Phase L/100km High Vehicle6.4

Low Phase Km/l Low Vehicle16.9

Low Phase Km/l High Vehicle15.6

Medium Phase L/100km Low Vehicle4.9

Medium Phase L/100km High Vehicle5.5

Medium Phase Km/l Low Vehicle20.4

Medium Phase Km/l High Vehicle18.2

High Phase L/100km Low Vehicle4.5

High Phase L/100km High Vehicle5

High Phase Km/l Low Vehicle22.2

Extra High Phase L/100km Low Vehicle5.6

Extra High Phase L/100km High Vehicle6.1

Extra High Phase Km/l Low Vehicle17.9

Extra High Phase Km/l High Vehicle16.4

Urban (mpg)51

Country/highway (mpg)67

Combined (mpg)47

Urban (miles Per UK Gallon)61

Country/highway (miles Per UK Gallon)81

Combined (miles Per UK Gallon)57

Combined Mpg Low Vehicle45

Combined Mpg High Vehicle41

Low Phase Mpg Low Vehicle40

Low Phase Mpg High Vehicle37

Medium Phase Mpg Low Vehicle48

Medium Phase Mpg High Vehicle43

High Phase Mpg Low Vehicle52

High Phase Mpg High Vehicle47

Extra High Phase Mpg Low Vehicle42

Extra High Phase Mpg High Vehicle39

Powertrain type

TypeCombustion

Energy recuperation

EngineYes

Insurance

Description12E
